Fruit Bevereage Drinks Juice/Mineral Water Filling Packaging
Machine Combi
To meet customers' requirement that the blow molding machine should
be high speed and energy saving, China-Beverage develops fully
automatic rotary blow molding machine, which combines the filling
and capping machine together in one combiblock system, mainly for
the drinking water, CSD and beverage filling line. The advantage of
this equipment is that it is highly intelligentized, with stable
performance, high efficiency and low production cost, and achieves
the national food sanitation standards. It is the preferred choice
for the large and middle scale beverage production line.
Application
It can be applied for PET Bottled drinking water, CSD, Juice, Tea,
Liquid milk, etc.
Capacity: 12000BPH-40000BPH.
Machine Frame
The machine frame is a welded structure of high quality carbon steel
with the surface anti-rust treated and coated. The machine frame is
wrapped with stainless steel sheet (SUS304).
Driving system of the 3-in-1 Unit is positioned under the machine
table. One main motor provides driving power via gear transmission.
The gear transmission system is an interleaved arrangement of steel
gears and nylon gears.
The output shaft of the main motor is equipped overload protection
to secure machine safety.
Main advantage
1,By combining functions of blowing, filling, and capping into one
machine, it has the advantages of simpler operation, lighter
packaging material, lower energy consumption, more reliable
quality, higher efficiency, smaller floor space, fewer operation,
adn less operation cost. The machine is equipped with safety door
and alarm device, ensuring the safety of workers to the largest
extend.
2,The warranty time is 2 years. During the time, if there is any
problem, China-Beverage will solve it immediately when we get the
notice, leaving no concerns to our customer.
Working process
►Blowing system
1. Adopt high techology of on-line ionic gas duster to clean the
preform.
2. High-speed blow valve group with high-speed network control
ensures blowing technic precision and unification.
3. Three-dimensional dynamic simulating design ensures exact and
reliable cam transmission and mesh.
4. High-pressure blow valve group optimum design helps save air a
lot.
5. Quick-change for mould.
6. Wearable aluminum alloy mould surface with special treatment of
hardness.
7. Key points automatic lubrication.
► Filling system
1). Filling machine adopts gravity filling way, the bottle mouth
rises to open filling valve, then filling starts. When the material
rises and plugs up to air returning hole, the filling stops; and
then the bottle moves down, leaves from the filling valves, which
means the whole filling process is finished.
2). High-speed and high-precision filling valve: 200ml/s, ± 2mm.
3). Servo drive system
4). With CIP cleaning function
5). The arrangement of steel gear and nylon gear is chiastic to
reduce noise.
► Capping system
1). Full bottles will enter capping machine via transition
starwheel. The anti-rotation knife of capper blocks bottle neck to
keep bottle vertical and prevent rotation. Capping heads keep
revolution and do rotation. Under effect of cam, the action of
gripping cap, sleeve cap, screwing cap and discharging cap to
finish the whole capping process. The finished bottles are
deliveryed via bottle-out starwheel onto bottle-out conveyor, and
then are sent out of the blowing-filling-capping combiblock system.
2). Magnetic constant torque, defective rate≤ 0.2%
3). Reversal caps ejecting device
4). No bottles, no feeding cap
Model
| Model | Capacity (500ml-water bottle) | Remark |
| ZYBFC8-28-10 | 16000Bph | Blowing:8 cavity, Filling: 28 heads, Capping: 10 heads |
| ZYBFC10-36-12 | 20000Bph | Blowing: 10 cavity, Filling: 36 heads, Capping: 12 heads |
| ZYBFC12-40-15 | 24000Bph | Blowing: 12 cavity, Filling: 40 heads, Capping: 15 heads |
| ZYBFC14-50-18 | 28000Bph | Blowing: 14 cavity, Filling: 50 heads, Capping: 18 heads |
| ZYBFC16-50-18 | 32000Bph | Blowing: 16 cavity, Filling: 50 heads, Capping: 18 heads |
| ZYBFC18-60-20 | 36000Bph | Blowing: 18 cavity, Filling: 60 heads, Capping: 20 heads |
| ZYBFC20-72-24 | 40000Bph | Blowing: 20 cavity, Filling: 72 heads, Capping: 24 heads |
Configuration
| Main material: | Aluminum alloy, carbon steel, stainless steel, alloy steel. |
| Bearing | High-quality homemade bearing and imported bearing(Japan and
Germany); Oilless bearing: IGUS |
| High-pressure air valve | NORGREN, EUGEN SEITZ, SMC, etc |
| Muffler | NORGREN |
| Pneumatic control line | FESTO, SMC, NORGREN. |
| Electric control system | MITSUBISHI, SIEMENS, SCHNEIDER. |
| Sensor | TURCK, SICK, B&R, OMRON, BANNER |
| Contactor | SIEMENS, Schneider. |
| Connecting terminal | PHOENIX, ABB |
